Product Introduction
When a TSX Micro PLC system requires a stable and protected power source, the Schneider Electric TSXPSY2600M Power Supply Module provides a dependable solution. Designed specifically for the TSX Micro PLC series, this module accepts a primary voltage input of 24 V DC (19.2 to 30 V) and delivers a total useful secondary power of 30 W. It handles inrush currents up to 100 A at 24 V, ensuring reliable startup even under demanding conditions.
Technical Specifications Breakdown
The TSXPSY2600M offers a well-rounded set of specifications that support robust industrial control applications. Key parameters include:
- Primary Voltage: 24 V DC (19.2 to 30 V)
- Total Useful Secondary Power: 30 W, split as 15 W at 5 V DC and 15 W at 24 V DC
- Current at Secondary Voltage: 3 A at 5 V DC and 0.6 A at 24 V DC (relay power supply)
- Input Current: ≤ 1500 mA at 24 V
- Inrush Current: 100 A at 24 V
These values mean the module can power both logic circuits (5 V DC) and relay outputs (24 V DC) from a single unit. The 30 W total capacity suits typical TSX Micro PLC configurations without overloading.
Industry Applications
In a packaging line where a TSX Micro PLC controls conveyor motors and sensors, the TSXPSY2600M provides the necessary 24 V DC for sensor power and relay outputs, plus 5 V DC for logic. Its IP20 degree of protection makes it suitable for indoor control cabinets where dust and moisture are minimal. The operating altitude range of 0 to 2000 meters covers most industrial facilities.
Installation & Setup Guidance
Mount the TSXPSY2600M in a clean, dry enclosure with adequate ventilation. Ensure the input voltage is within 19.2 to 30 V DC and that the total secondary load does not exceed 30 W. Use appropriate wire gauges for the 3 A and 0.6 A outputs. The internal fuse (3.5 A, 5 x 20 mm, time-delayed) protects the primary circuit; replace only with the same type if it blows.
Maintenance & Reliability
The module operates reliably in temperatures from 0 to 60 °C and can be stored between -25 and 70 °C. Relative humidity should remain 10 to 95% without condensation during operation. Periodically inspect the green LED for voltage presence and the red LED for battery faults. Clean the enclosure with a dry cloth; avoid solvents. Regular checks help extend service life and prevent unexpected downtime.
Compatibility & Integration
The TSXPSY2600M is designed exclusively for the Schneider TSX Micro PLC family. It integrates directly into the PLC rack, providing power to the CPU and I/O modules. No additional adapters are required. Verify that your TSX Micro base unit accepts this power supply module before ordering.
Selection Guide & Purchasing Advice
Before purchasing, confirm that your TSX Micro PLC system requires a 24 V DC input power supply with a 30 W output. The TSXPSY2600M is a standard module format. SpareTechPLC stocks this unit and can advise on compatibility with your specific PLC configuration. Contact our team for current availability and lifecycle status.
Frequently Asked Questions (FAQs)
Q: What is the total secondary power output of the TSXPSY2600M?
A: The total useful secondary power is 30 W, with 15 W available at 5 V DC and 15 W at 24 V DC.
Q: What protection features does this module include?
A: It includes an internal time-delayed fuse (3.5 A, 5 x 20 mm), overload protection, overvoltage protection, and short-circuit protection.
Q: Can the TSXPSY2600M operate at high altitudes?
A: Yes, it operates at altitudes from 0 to 2000 meters.
Q: What do the front panel LEDs indicate?
A: A green LED indicates presence of voltages, and a red LED signals a battery fault.
Q: Is this module compatible with other Schneider PLC families?
A: No, it is specifically designed for the TSX Micro PLC series only.
