Product Overview
When precise motion control is critical in CNC machining, the FANUC A06B-6096-H106 servo amplifier delivers the performance you need. This single-axis unit provides a rated power of 9.1 kW and an output voltage of 230V, making it a reliable choice for demanding automation tasks. Part of the A06B product line from FANUC, it is built to integrate seamlessly into existing systems.
Technical Specifications Breakdown
- Rated Power: 9.1 kW – sufficient for medium to high-power single-axis applications.
- Output Voltage: 230V – matches common motor and drive requirements.
- Input Voltage: 283-325V – ensures stable operation within this range.
- Operating Temperature: 0 to 40 degrees Celsius – suitable for typical factory floor environments.
- Maximum Vibration: 5G – withstands dynamic conditions without performance loss.
- Maximum Altitude: 1000 meters above sea level – maintains consistent output at elevated locations.
- Dimensions: 11.9 x 14 x 3.3 inches – compact form factor for standard enclosures.
- Weight: 13.00 lbs (5.90 kg) – manageable for installation and replacement.
Industry Applications
- CNC Milling Machines: The A06B-6096-H106 drives spindle or axis motors with precision, handling continuous duty cycles in metal cutting.
- Robotic Arms: Single-axis control suits articulated joints requiring accurate torque and speed regulation.
- Automated Assembly Lines: Reliable power delivery reduces downtime in high-throughput pick-and-place systems.
Installation & Setup Guidance
Mount the amplifier securely using the provided dimensions (11.9 x 14 x 3.3 inches) to ensure proper airflow. Connect the input power within the 283-325V range and the motor to the 230V output. Verify that ambient temperature stays between 0 and 40 degrees Celsius. For vibration-prone environments, use dampening mounts to stay within the 5G limit.
Maintenance & Reliability
Regularly inspect the amplifier for dust buildup and ensure cooling vents remain unobstructed. Check input voltage stability to avoid exceeding the 283-325V range. Operate below 1000 meters altitude to guarantee full performance. Following these steps extends service life and maintains the 9.1 kW output capability.
Compatibility & Integration
This servo amplifier is designed for CNC applications and works with FANUC control systems. It supports single-axis configurations, making it a direct replacement for similar units in the A06B series. Verify motor voltage (230V) and input supply (283-325V) before integration.
Selection Guide & Purchasing Advice
Before purchasing the A06B-6096-H106, confirm your system requires a single-axis amplifier with 9.1 kW power and 230V output. Check that your input voltage matches the 283-325V range. SpareTechPLC stocks this model and can advise on compatibility with your existing FANUC components. Contact us for current availability and lifecycle status.
Frequently Asked Questions
Q1: What is the rated power of the A06B-6096-H106?
A1: The rated power is 9.1 kW.
Q2: What input voltage does this servo amplifier require?
A2: It requires an input voltage between 283V and 325V.
Q3: Can this amplifier be used in high-vibration environments?
A3: Yes, it can withstand up to 5G of vibration.
Q4: What is the operating temperature range?
A4: The operating temperature range is 0 to 40 degrees Celsius.
Q5: Is this unit compatible with multi-axis systems?
A5: No, it is designed for single-axis applications only.
