Product Overview
The FANUC A06B-6150-H045 is a servo amplifier module designed for high-performance motor control in industrial automation systems. This 3-phase unit delivers robust power handling with a rated output power of 50 kW. It operates with an input voltage range of 400-480 VAC and can accommodate a rated input current of 92 Amps at 400 volts. The module is part of the A06B product line from FANUC, a trusted name in automation.
Technical Specifications Breakdown
Key performance parameters of the A06B-6150-H045 include:
- Input Voltage: 400-480 VAC, 3-phase
- Rated Input Current: 92A at 400V
- Input Frequency: 50/60 Hz
- Output Voltage: 283-339 VDC
- Rated Output Power: 50 kW
- Ambient Operating Temperature: 0°C to 55°C
- Weight: 35.00 lbs (15.88 kg)
The output voltage range of 283-339 VDC ensures stable DC bus power for connected servo motors. The 50/60 Hz input frequency compatibility makes this module suitable for global installations. The operating temperature range of 0°C to 55°C allows reliable performance in typical industrial environments.
Industry Applications
The A06B-6150-H045 servo amplifier is ideal for applications requiring precise motor control and high power output. Common use cases include:
- CNC Machining Centers: The 50 kW rated output power supports heavy-duty spindle drives and axis motors in milling, turning, and grinding machines.
- Robotics: The 3-phase input and robust current handling (92A at 400V) make this module suitable for large industrial robots requiring smooth acceleration and deceleration.
- Automated Assembly Lines: The wide input voltage range (400-480 VAC) provides flexibility in facilities with varying power supply conditions.
Installation & Setup Guidance
When installing the A06B-6150-H045, ensure the following:
- Verify that the input power source matches the module's specifications: 400-480 VAC, 3-phase, 50/60 Hz.
- Use appropriately rated wiring and circuit protection for the 92A input current at 400V.
- Mount the module in a location that maintains ambient temperature between 0°C and 55°C to prevent overheating.
- Ensure adequate ventilation around the unit to dissipate heat generated during operation.
- Follow all local electrical codes and safety regulations during installation.
Maintenance & Reliability
To maximize the service life of the A06B-6150-H045, perform regular inspections:
- Check for dust accumulation on cooling fins and fans. Clean as needed to maintain airflow.
- Verify that all electrical connections remain tight and free from corrosion.
- Monitor operating temperature to ensure it stays within the 0°C to 55°C range.
- Periodically test the module's output voltage (283-339 VDC) to confirm proper regulation.
Routine maintenance helps prevent unexpected downtime and extends the operational life of the amplifier.
Buying Guide & Purchasing Advice
Before purchasing a FANUC A06B-6150-H045, confirm the following:
- Your application requires a 50 kW servo amplifier with 400-480 VAC 3-phase input.
- The module's weight of 35.00 lbs (15.88 kg) is acceptable for your mounting setup.
- The ambient temperature in your installation area stays within 0°C to 55°C.
SpareTechPLC offers this servo amplifier module with detailed specifications to help you make an informed decision. Contact our team for current availability and pricing.
Please verify current lifecycle status and availability with SpareTechPLC before ordering.
