Product Introduction
When high-demand industrial systems require stable and efficient power conversion, the FANUC A06B-6150-H030 power supply module delivers robust performance. This module is part of the FANUC A06B product line and is engineered to convert 3-phase AC input into a regulated DC output for demanding automation equipment.
Technical Specifications Breakdown
The FANUC A06B-6150-H030 operates on a 3-phase input voltage range of 400 to 480 VAC, with an input current of 63A at 400V and a frequency of 50/60 Hz. It provides an output voltage of 565 to 679 VDC and a rated output power of 35 kW. The module weighs 25.00 lbs (11.34 kg) and functions within an ambient operating temperature of 0°C to 55°C. It can handle ambient humidity up to 90% RH without condensation and can be stored at temperatures from -20°C to 60°C.
Industry Applications
This power supply module is ideal for powering CNC machines, robotic systems, and industrial motor drives that require a stable DC bus. For example, in a high-speed machining center, the A06B-6150-H030 ensures consistent 565-679 VDC output, supporting peak power demands up to 35 kW. Its 3-phase input design minimizes line harmonics, making it suitable for facilities with sensitive equipment.
Installation & Setup Guidance
Mount the module in a clean, dry cabinet with adequate ventilation to maintain ambient temperature below 55°C. Ensure the 3-phase input voltage is within 400-480 VAC and that the supply can deliver at least 63A at 400V. Use appropriately rated cables and fuses. Verify that the output DC voltage range (565-679 VDC) matches the load requirements before powering on.
Maintenance & Reliability
Regularly inspect the module for dust accumulation on cooling fins and ensure fans (if present) operate freely. Check input and output connections for tightness. The module's wide operating temperature range (0°C to 55°C) and humidity tolerance (90% RH) contribute to long service life in harsh environments. Periodic thermal imaging can identify potential hot spots before failures occur.
Compatibility & Integration
The A06B-6150-H030 integrates seamlessly with FANUC servo amplifiers and spindle drives that require a 565-679 VDC bus. It is compatible with FANUC Series 0i, 16i, 18i, and 30i CNC systems. For other brands, verify that the DC bus voltage and power rating (35 kW) match the connected equipment.
Selection Guide & Purchasing Advice
Before ordering, confirm that your system requires a 35 kW, 3-phase input power supply with 565-679 VDC output. Check physical dimensions and mounting provisions to ensure fit in your cabinet. SpareTechPLC stocks the FANUC A06B-6150-H030 and can advise on compatibility with your existing FANUC components.
Frequently Asked Questions
Q1: What is the input voltage range for the A06B-6150-H030?
A: The input voltage range is 400-480 VAC, 3-phase, 50/60 Hz.
Q2: What output voltage does this module provide?
A: The output voltage is 565-679 VDC, with a rated power of 35 kW.
Q3: What is the maximum ambient operating temperature?
A: The module operates from 0°C to 55°C.
Q4: Can this module be used with single-phase input?
A: No, it requires a 3-phase input.
Q5: What is the weight of the A06B-6150-H030?
A: It weighs 25.00 lbs (11.34 kg).
