Product Overview
When your CNC or robotics system demands precise motion control, the FANUC A06B-6096-H204 Servo Amplifier delivers reliable performance. This unit operates on a 3-phase AC power supply with a voltage range of 200-240V AC, making it suitable for diverse industrial environments. It supports both analog and pulse control, offering flexibility for various applications.
Key Specifications
- Manufacturer: FANUC
- Product Type: Servo Amplifier
- Part Number: A06B-6096-H204
- Weight: 12.00 lbs (5.44 kg)
- Power Supply Voltage: 200-240V AC, 3-Phase
- Maximum Output Voltage: 240V AC
- L-Axis Output Current: 3 Amps
- M-Axis Output Current: 12.5 Amps
- Operating Temperature: 0 to 40 degrees Celsius
- Maximum Vibration: 5G
- Maximum Altitude: 1000 Meters Above Sea Level
- Cooling: Fan Cooling Supported
- Approximate Dimensions: 380 x 150 x 250 mm
Industry Applications
This servo amplifier excels in CNC machining centers and robotic arms. In a CNC milling setup, the A06B-6096-H204 drives axis motors with its L-axis output of 3 Amps and M-axis output of 12.5 Amps, ensuring smooth cutting operations. For robotics, it provides the torque needed for precise pick-and-place tasks. Its ability to handle temperatures up to 40 degrees Celsius and vibrations up to 5G makes it a robust choice for factory floors.
Installation and Setup Guidance
Mount the A06B-6096-H204 in a clean, dry location with adequate airflow for its fan cooling system. Ensure the 3-phase AC power supply matches the 200-240V AC input range. Connect the L-axis and M-axis outputs to the corresponding servo motors. Verify that the operating environment stays within the 0 to 40 degrees Celsius temperature range and does not exceed 1000 meters above sea level.
Maintenance and Reliability
Regularly inspect the fan cooling system for dust buildup to maintain thermal performance. Check all electrical connections for tightness. The amplifier's robust design withstands 5G vibration, but periodic inspection of mounting hardware is recommended. Following these steps extends service life and reduces unplanned downtime.
Compatibility and Integration
The A06B-6096-H204 integrates seamlessly with FANUC CNC controllers and robotics systems. It supports analog and pulse control signals, allowing connection to various motion controllers. Verify that your system's power requirements align with the 200-240V AC, 3-phase input.
Selection Guide and Purchasing Advice
Before ordering, confirm that the A06B-6096-H204 matches your application's voltage and current needs. Compare its 3 Amps L-axis and 12.5 Amps M-axis outputs with your motor specifications. SpareTechPLC stocks this servo amplifier and can help verify compatibility with your existing FANUC system. Contact us for current availability and lifecycle status.
Frequently Asked Questions
Q: What is the power supply requirement for the A06B-6096-H204?
A: It requires a 3-phase AC power supply with a voltage range of 200-240V AC.
Q: What are the output current ratings for this servo amplifier?
A: The L-axis output current is 3 Amps, and the M-axis output current is 12.5 Amps.
Q: Can this amplifier be used in high-altitude environments?
A: Yes, it is rated for operation up to 1000 meters above sea level.
Q: Does the A06B-6096-H204 support analog control?
A: Yes, it supports both analog and pulse control signals.
Q: What cooling method does this unit use?
A: It uses fan cooling to maintain optimal operating temperatures.
