Product Overview
When your CNC machine or robotic system demands precise dual-axis motion control, the FANUC A06B-6096-H209 servo amplifier delivers reliable performance. This two-axis unit handles input voltages from 283 to 325 volts and provides a maximum output voltage of 230 volts. With a power rating of 7.5 kW, it supports demanding industrial tasks while maintaining efficiency.
Technical Specifications Breakdown
The A06B-6096-H209 offers balanced output on both axes. The L-axis output current is 12.5 Amps, and the M-axis output current is also 12.5 Amps. This symmetry simplifies system design and ensures consistent torque delivery. The amplifier operates within a temperature range of 0 to 40 degrees Celsius, making it suitable for typical factory environments. It withstands maximum vibration of 5G and functions at altitudes up to 1000 meters above sea level.
Industry Applications
This servo amplifier excels in CNC machining centers and robotic workcells. In a CNC milling application, the dual-axis control manages simultaneous movement of two axes, such as X and Y, with 12.5 Amps per axis. For robotic pick-and-place systems, the A06B-6096-H209 coordinates two servo motors to achieve smooth, precise motion. Its 7.5 kW power rating supports medium-duty cycles without overheating.
Installation & Setup Guidance
Mount the A06B-6096-H209 in a clean, dry cabinet with adequate airflow. Ensure the input voltage source matches the 283-325 V range. Connect the L-axis and M-axis motors to their respective terminals, observing correct polarity. Use shielded cables for encoder feedback to minimize electrical noise. Verify that the operating environment stays within 0 to 40 degrees Celsius and does not exceed 1000 meters altitude. After wiring, power up and check for normal LED indications.
Maintenance & Reliability
Periodically inspect the amplifier for dust accumulation on heat sinks and cooling fans. Clean using low-pressure compressed air. Check all power and signal connections for tightness. Monitor the operating temperature; if it approaches 40 degrees Celsius, improve ventilation. The unit's 5G vibration tolerance means it can handle moderate shock, but avoid mounting near heavy impact sources. Regular inspection helps extend service life and prevent unplanned downtime.
Compatibility & Integration
The FANUC A06B-6096-H209 is designed for CNC applications and robotics applications. It integrates with FANUC CNC controllers and robotic systems. The two-axis configuration supports common motion control architectures. For specific controller compatibility, consult your system documentation or contact SpareTechPLC for guidance.
Selection Guide & Purchasing Advice
Before ordering, verify that your system requires a two-axis servo amplifier with 12.5 Amps per axis and 7.5 kW power. Confirm the input voltage source falls within 283-325 V. The A06B-6096-H209 weighs 25.00 lbs (11.34 kg), so plan for proper mounting support. SpareTechPLC stocks this model and can assist with availability and shipping details. Please verify current lifecycle status with SpareTechPLC before ordering.
Frequently Asked Questions
Q: What is the input voltage range for the A06B-6096-H209?
A: The input voltage range is 283 to 325 volts.
Q: How many axes does this servo amplifier control?
A: It controls two axes, designated L-axis and M-axis.
Q: What is the output current per axis?
A: Both the L-axis and M-axis output 12.5 Amps each.
Q: What is the power rating of this amplifier?
A: The power rating is 7.5 kW.
Q: Can this unit be used in robotics applications?
A: Yes, it supports robotics applications as well as CNC applications.
