Product Overview
When your industrial automation system demands reliable and efficient power conversion, the FANUC A06B-6110-H030 power supply module delivers. As part of the A06B product line, this module is engineered for 3-phase electrical systems, providing a stable DC output for your machinery. With a rated output power of 35 kW and an efficiency of 91%, it minimizes energy waste and supports high-performance operations.
Technical Specifications Breakdown
Let's examine the key parameters that make the A06B-6110-H030 a solid choice for your power supply needs.
- Input Voltage and Current: The module accepts an input voltage range of 200-240 VAC and draws a maximum input current of 127A at 200V. This ensures substantial power availability for demanding loads.
- Output Characteristics: It generates a DC output voltage of 283-339 VDC, with a rated output current of 30A and a maximum output current of 35A. This allows it to handle both continuous and peak power demands.
- Efficiency and Power Factor: With an efficiency rating of 91% and a power factor correction of 0.98, the module converts AC power to DC with minimal losses and improved power quality.
- Environmental Tolerance: The module operates reliably in ambient temperatures from 0°C to 55°C and can handle humidity up to 90% RH (non-condensing), making it suitable for various industrial environments.
Industry Applications
In manufacturing plants, the A06B-6110-H030 powers servo drives and CNC machinery, ensuring consistent performance. For example, in a high-speed machining center, its 35 kW output and 30A continuous current support multiple axes simultaneously, reducing downtime. The module's high efficiency also lowers operational costs over time, aligning with a cost-benefit perspective.
Installation & Setup Guidance
When installing the A06B-6110-H030, ensure the input power source matches the specified 200-240 VAC, 3-phase, 50/60 Hz. Use appropriately rated wiring to handle the 127A input current at 200V. Mount the module in a clean, ventilated enclosure to maintain ambient temperatures below 55°C. Verify that the output DC voltage range (283-339 VDC) aligns with your load requirements before connecting.
Maintenance & Reliability
To maximize the lifespan of the A06B-6110-H030, perform periodic inspections of the cooling fans and air filters. Check for any signs of condensation, as the module is rated for 90% RH non-condensing. Regular cleaning of dust buildup helps maintain the 91% efficiency rating. By following these steps, you reduce the risk of unexpected failures and extend service intervals.
Compatibility & Integration
The FANUC A06B-6110-H030 integrates seamlessly with FANUC servo amplifiers and CNC controllers that require a 283-339 VDC power bus. It is compatible with systems designed for 3-phase AC input. For specific integration details, consult your system documentation or contact SpareTechPLC for guidance.
Selection Guide & Purchasing Advice
Before purchasing the A06B-6110-H030, verify that your application requires a 35 kW power supply with 30A continuous output. Check the input voltage availability (200-240 VAC, 3-phase) and ensure your load can accept the 283-339 VDC output. SpareTechPLC offers this module with fast shipping and expert support to help you make the right choice.
Frequently Asked Questions
Q: What is the input voltage range for the A06B-6110-H030?
A: The module accepts 200-240 VAC, 3-phase, at 50/60 Hz.
Q: What is the maximum output current?
A: The maximum output current is 35A, with a rated continuous output of 30A.
Q: Can this module operate in high-humidity environments?
A: Yes, it can handle up to 90% RH, provided no condensation occurs.
Q: What is the efficiency of the A06B-6110-H030?
A: The module achieves 91% efficiency, reducing energy losses.
Q: Is the A06B-6110-H030 still in production?
A: Please verify current lifecycle status and availability with SpareTechPLC before ordering.
