Product Overview
When precision motion control demands reliable power amplification, the FANUC A06B-6114-H208 servo amplifier module provides a robust solution. This component operates within a DC input voltage range of 283 to 339 volts and delivers a rated input power of 10 kW. Designed for industrial environments, it supports input frequencies of 50 or 60 Hz, making it versatile for global applications.
Technical Specifications Breakdown
The A06B-6114-H208 offers key performance parameters that define its capabilities:
- Input Voltage: 283-339 VDC ensures stable operation across varying DC supplies.
- Rated Input Power: 10 kW enables handling of high-demand motion tasks.
- Output Voltage: 200-240 VAC provides compatible power for connected servo motors.
- Rated Output Current: 13 A for the L-axis and 19 A for the M-axis, allowing control of multiple axes with different load requirements.
- Output Frequency Range: 0.1 to 800 Hz offers flexibility for precise speed and position control.
- Ambient Temperature Range: Operates from 0°C to 55°C, suitable for typical factory floor conditions.
- Ambient Humidity: Rated for 90% RH or less without condensation.
Industry Applications
Manufacturing facilities that require accurate axis positioning benefit from the A06B-6114-H208. For example, in CNC machining centers, this servo amplifier module drives spindle and feed axes with the 13A and 19A current outputs. The wide output frequency range supports both high-speed and low-speed operations, enhancing process flexibility.
In robotic assembly lines, the module's 10 kW power capacity enables rapid acceleration and deceleration, reducing cycle times. The robust environmental ratings ensure reliable performance even in humid or warm conditions.
Installation & Setup Guidance
Mount the A06B-6114-H208 in a clean, dry enclosure with adequate ventilation to maintain ambient temperature below 55°C. Ensure the DC input voltage stays within 283-339 VDC. Connect output wiring for the L-axis and M-axis according to the load current ratings—13A and 19A respectively. Verify that the output frequency settings match the motor requirements within the 0.1 to 800 Hz range.
Maintenance & Reliability
Regularly inspect the module for dust accumulation and ensure cooling fans (if present) operate freely. Check that ambient humidity remains below 90% RH to prevent condensation. Periodically verify input voltage stability and output current levels. Following these steps extends service life and minimizes unplanned downtime.
Compatibility & Integration
This servo amplifier module integrates with FANUC control systems and servo motors that accept 200-240 VAC output. It works with controllers that provide appropriate command signals for the L and M axes. Verify compatibility with your existing FANUC components before installation.
Selection Guide & Purchasing Advice
Before purchasing the A06B-6114-H208, confirm that your system requires a 10 kW servo amplifier with 283-339 VDC input. Check the output current needs for each axis—13A for L-axis and 19A for M-axis. SpareTechPLC stocks this module and can assist with availability and lifecycle status. Contact us to verify current stock and ensure the part meets your application requirements.
