Product Overview
When your control system demands reliable field wiring and easy module swaps, the GE Fanuc Versamax IC200CHS025 compact spring-style I/O carrier delivers. This carrier provides mounting, field wiring, and backplane communications for Versamax I/O modules. Compatible modules mount vertically onto the IC200CHS025, allowing removal without disturbing field wiring. Part of the Versamax product line, this carrier uses spring-style terminals for fast, tool-less connections.
Technical Specifications Breakdown
The IC200CHS025 offers 36 IEC box-style terminals. Single wire connections accept AWG 14 to AWG 22 gauge copper wires. Dual wire connections accept AWG 18 gauge wires. The carrier supports vertical I/O module mounting. For proper airflow, maintain a minimum of 2 inches of vertical spacing and 1 inch of horizontal spacing around the carrier. The operating temperature range is -40 to 60 degrees Celsius.
Industry Applications
In manufacturing environments where space is tight, the compact spring-style design of the IC200CHS025 simplifies wiring and reduces panel clutter. Use it in assembly lines, material handling systems, or packaging machinery where quick module replacement minimizes downtime. The vertical mounting orientation suits DIN-rail installations where horizontal space is limited.
Installation & Setup Guidance
Mount the IC200CHS025 on a DIN rail, ensuring adequate spacing for airflow. Connect field wiring to the 36 IEC box-style terminals using single wires (AWG 14-22) or dual wires (AWG 18). Insert compatible Versamax I/O modules vertically onto the carrier until they latch securely. Use the keying dials to ensure only the correct module type is installed. The latch hole provides secure fastening between module and carrier.
Maintenance & Reliability
Periodically inspect the spring terminals for signs of corrosion or loose connections. Keep the operating environment within -40 to 60 degrees Celsius to ensure reliable performance. Verify that the 1-inch horizontal and 2-inch vertical spacing requirements are maintained around the carrier to prevent overheating. No special cleaning procedures are required beyond routine visual checks.
Compatibility & Integration
The IC200CHS025 is designed exclusively for the GE Fanuc Versamax series. It works with any Versamax I/O module that mounts vertically. The carrier provides backplane communications to the controller. Use carrier-to-carrier mating connectors to expand your system. Always verify module compatibility with your specific Versamax CPU before ordering.
Selection Guide & Purchasing Advice
Before purchasing the IC200CHS025, confirm your I/O modules require a compact spring-style carrier with vertical mounting. Check that your wire gauges fall within AWG 14-22 for single wires or AWG 18 for dual wires. SpareTechPLC stocks the IC200CHS025 and can advise on current lifecycle status and availability. Contact us to ensure this carrier meets your system requirements.
Frequently Asked Questions
Q: What is the maximum number of I/O points supported by the IC200CHS025?
A: The IC200CHS025 supports a maximum of 32 I/O points with four common/power connections.
Q: Can I use the IC200CHS025 with terminal-style I/O carriers?
A: No. The IC200CHS025 is a compact spring-style I/O carrier. It is not compatible with connector-style or terminal-style carriers.
Q: What wire gauge is required for dual wire connections?
A: Dual wire connections require AWG 18 gauge copper wires.
Q: What is the operating temperature range for this carrier?
A: The recommended working temperature range is -40 to 60 degrees Celsius.
Q: Does the IC200CHS025 include keying dials?
A: Yes, keying dials ensure the installation of the proper type of module.
