Lenze K-D M12W-5P-5m-PVC Connection Cable – 5m M12 Angled 5-Pin

Technical Specifications Breakdown

Key parameters for the K-D M12W-5P-5m-PVC are listed below for quick reference:

Industry Applications

This cable is a workhorse in automated manufacturing, packaging lines, and material handling systems. Its angled connector is particularly useful in confined spaces, such as inside machine enclosures or near conveyor rollers, where straight connectors would be impractical. The 5-pin configuration supports advanced sensor functions like dual outputs or additional signal lines, giving engineers flexibility in their I/O design.

Because the cable is rated for both AC and DC, you can standardize on one cable type across multiple machines, simplifying your spare parts inventory. The PVC jacket resists oils and chemicals commonly found in industrial settings, reducing the risk of premature failure.

Installation & Setup Guidance

Before installation, verify that the operating voltage and current of your application do not exceed the cable's ratings. For 5-pin versions, keep the voltage at or below 125 VAC/DC; for 3/4-pin versions, up to 250 VAC/DC is permissible. The cable is designed for both fixed and flexible wiring, but observe the temperature limits: for fixed installations, the range is -30°C to +70°C; for flexible routing, it is -5°C to +70°C.

When routing the cable, avoid sharp bends. The minimum bending radius is 10 times the sheath diameter, which ensures the internal conductors are not stressed. Use the recommended torque of 0.6 Nm when tightening the screw fitting to create a secure, IP-rated seal. The diecast zinc, nickel-plated connector body is self-locking, so it will stay put even under vibration.

Maintenance & Reliability

Periodically inspect the cable for cuts, abrasions, or signs of wear, especially where it flexes or contacts sharp edges. Check that the connector is still tightly seated and that the locking nut has not loosened. Clean the connector contacts with a dry cloth if they become dirty; do not use solvents that could damage the PVC jacket.

The cable's insulation class (Category I) and robust construction contribute to long service life. In environments with extreme temperatures or chemical exposure, verify that the PVC material is compatible with your specific conditions. Regular inspection every 6 to 12 months is a good practice to catch issues early.

Compatibility & Integration

The K-D M12W-5P-5m-PVC is a standard M12 connector, making it compatible with a wide range of sensors, actuators, and I/O blocks from various manufacturers. The 5-pin layout follows industry-standard wiring, so you can easily integrate it into your existing automation architecture. Whether you are connecting a proximity sensor, a photoelectric sensor, or a valve manifold, this cable provides a reliable link.

Selection Guide & Purchasing Advice

When selecting a connection cable, consider the environment, the required length, and the connector orientation. The angled connector of this model helps in tight spaces, but if you need a straight connector, other variants are available. Always confirm the pin count and voltage rating match your device.

At AutoDCSTech, we stock the Lenze K-D M12W-5P-5m-PVC to ensure you get genuine, factory-specified components. Our team can help you verify compatibility and availability. Please verify current lifecycle status and availability with AutoDCSTech before ordering.

Troubleshooting & Common Issues

If you experience intermittent signals, first check that the connector is fully tightened. A loose connection can cause erratic behavior. Inspect the cable for any cuts or kinks that might break a conductor. If the cable has been flexed beyond its rated bending radius, internal wires may have fractured, leading to open circuits.

If the cable is exposed to temperatures outside its rated range, the PVC jacket may become brittle or soft, compromising protection. Replace the cable if you notice any physical damage. For persistent issues, verify that the connected device is within the cable's electrical ratings.
