TSXPSY5500M Power Supply: Reliable Power for TSX Micro PLCs

Evolution of Industrial Power Systems

The journey of industrial automation has always been tied to the reliability of power delivery. Early systems relied on bulky, single-voltage supplies that struggled with fluctuating grid conditions. As factories embraced digital control, the demand for compact, versatile power modules grew. Today, modular PLC platforms like the TSX Micro series depend on power supplies that can adapt to global voltage standards while maintaining stable output.

The Schneider Electric TSXPSY5500M embodies this evolution, offering a flexible solution for modern control cabinets. It supports both 200-240 V AC and 100-120 V AC inputs, making it a practical choice for facilities operating across different regions. This adaptability reduces the need for multiple SKUs and simplifies inventory management for system integrators.

Introducing the TSXPSY5500M

When a control system loses power, even for milliseconds, production lines can halt and data can be corrupted. The TSXPSY5500M power supply module from Schneider Electric addresses this challenge head-on. Designed for the TSX Micro PLCs series, it provides dependable power to keep your automation running smoothly.

This module operates on a primary voltage of 200-240 V AC (190-264 V) or 100-120 V AC (85-140 V), with a network frequency of 50/60 Hz. It delivers a total useful secondary power of 50 W, split into 35 W at 5 V DC and 19 W at 24 V DC. These outputs support logic circuits, sensors, and relay loads, making it a versatile building block for control panels.

Key Technical Specifications

Understanding the TSXPSY5500M's specifications helps engineers design robust systems. The module accepts input currents of 500 mA at 240 V and 1700 mA at 100 V, with an inrush current of 38 A at both voltage levels. This ensures stable startup even with capacitive loads.

For secondary outputs, it provides 7 A at 5 V DC for logic, and 0.8 A at 24 V DC for both sensor and relay power supplies. The module also includes an internal time-delayed fuse rated at 4 A (5 x 20 mm) for primary circuit protection. Overload, overvoltage, and short-circuit protection on the secondary circuit safeguard connected devices.

Environmental resilience is another highlight. The TSXPSY5500M operates in temperatures from 0 to 60 °C and can be stored from -25 to 70 °C. It tolerates relative humidity of 10 to 95% without condensation during operation, and 5 to 95% during storage. With an IP20 degree of protection and pollution degree 2, it suits typical industrial control cabinets.

Applications in Modern Manufacturing

The TSXPSY5500M finds use in a variety of industrial settings. In packaging lines, it powers PLCs that control conveyor timing and labeling stations. Its dual-voltage input allows the same module to be used in plants with different utility standards, simplifying global equipment rollouts.

In material handling systems, the 24 V DC sensor supply (0.8 A) reliably powers proximity sensors and limit switches. The 5 V DC output (7 A) supports high-speed logic circuits, ensuring precise control of sorting mechanisms. The module's wide operating temperature range makes it suitable for environments near ovens or refrigeration units.

Real-World Application Example

Consider a typical automotive assembly line where a TSX Micro PLC manages a robotic welding cell. The TSXPSY5500M provides stable 5 V DC power to the PLC's CPU and I/O modules, while the 24 V DC output energizes solenoid valves and indicator lights. The module's overvoltage protection helps prevent damage from grid transients, reducing unplanned downtime.

In a water treatment facility, the same power supply could support remote terminal units monitoring flow and pressure. The 47-63 Hz frequency tolerance ensures reliable operation even with backup generators that may vary in output. This flexibility makes the TSXPSY5500M a dependable choice for critical infrastructure.

Integration with TSX Micro PLCs

The TSXPSY5500M is specifically engineered for the TSX Micro PLCs product line. It mounts directly onto the PLC rack, providing a seamless power interface. The module's local signaling includes three LEDs: a green LED for sensor voltage presence, a green LED for main voltage OK, and a red LED for battery fault. These indicators allow quick visual diagnostics.

For system designers, the module's insulation resistance of ≥100 MOhm (primary/ground and primary/secondary) ensures safe isolation. Dielectric strength of 2000 V between primary and earth, and primary and secondary, meets stringent safety standards. The module also complies with standards such as UL 508, CSA C22.2 No 142, and IEC 61131-2, among others.

Business Value and ROI

Investing in a reliable power supply like the TSXPSY5500M reduces total cost of ownership. Its wide input voltage range eliminates the need for step-down transformers in many installations, saving space and installation costs. The robust protection features minimize the risk of equipment failure, reducing maintenance expenses.

With a net weight of 1.37 lb (0.62 kg) and a compact double module format, the TSXPSY5500M is easy to handle and install. Its operating altitude range of 0 to 2000 meters makes it suitable for high-altitude facilities. These attributes contribute to faster commissioning and lower lifecycle costs.
