Product Overview
The Schneider 170BSM01600 is a discrete input simulator from the Modicon Momentum series. It is designed to simulate discrete input signals for testing and commissioning automation systems. This component helps engineers validate I/O wiring and logic without live field devices, reducing downtime and risk during startup.
Technical Specifications Breakdown
Key parameters for the 170BSM01600 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Product Type | Input Simulator |
| Input Type | Discrete |
| Number of Channels | 16 |
| Discrete Input Voltage | 24 VDC |
| Local Signaling | LEDs |
| Number of LED Indicators | 7 |
| Mounting | DIN rail mounting |
| Min. Operating Temp. | -20°C |
| Max. Operating Temp. | 55°C |
| Min. Storage Temp. | -40°C |
| Max. Storage Temp. | 75°C |
| Relative Humidity | 95% or less (non-condensing) |
| Environment | No corrosive gases |
Industry Applications
This input simulator is widely used in manufacturing and process control for pre-commissioning checks. Engineers can simulate 16 discrete signals at 24 VDC to test PLC logic and HMI responses. It is particularly useful in automotive assembly lines and packaging systems where quick validation of safety interlocks and sensor inputs is critical. By using this simulator, teams avoid wiring errors and reduce commissioning time.
Installation & Setup Guidance
Mount the 170BSM01600 on a standard DIN rail within the control panel. Ensure the ambient temperature stays between -20°C and 55°C. Connect the discrete input channels to the corresponding I/O base using appropriate wiring. The seven LED indicators provide immediate visual feedback for each active channel. Verify that the environment is free of corrosive gases to maintain reliable operation.
Maintenance & Reliability
Periodically inspect the LED indicators and DIN rail mounting for secure fit. Keep the unit clean and dry, as relative humidity must remain at 95% or less (non-condensing). Avoid exposure to corrosive gases. No internal adjustments are required; if performance degrades, verify wiring and power supply before replacement.
Compatibility & Integration
The 170BSM01600 is designed for the Modicon Momentum automation platform. It serves as a discrete input simulator for discrete I/O bases. Integration is straightforward with standard Momentum I/O modules.
Selection Guide & Purchasing Advice
When selecting an input simulator, confirm that your system requires 16 discrete channels at 24 VDC. The 170BSM01600 is a reliable choice for testing and simulation. Contact AutoDCSTech for current availability and lifecycle status before ordering.
Availability & Condition at AutoDCSTech
| Part Number | 170BSM01600 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
