Product Overview
The 170BNP67100 is a communication interface module designed by Schneider Electric for the Modicon Momentum product line. It supports the Modbus Plus protocol, a widely adopted network standard in industrial automation, and operates with a current draw of 200 mA. This module ensures efficient data transmission between controllers and I/O devices, making it a critical component for integrated systems.
Technical Specifications Breakdown
Key parameters for the 170BNP67100 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Type | Communication Interface Module |
| Product Line | Modicon Momentum |
| Part Number | 170BNP67100 |
| Current Draw | 200 mA |
| Protocol Support | Modbus Plus |
| Status Indicators | LED |
| Connector Type | DB9 Female |
| Compatibility | TSX Momentum I/O |
| Number of Ports | 1 |
| Operating Temperature | 0°C to +60°C |
| Baud Rate | 1 Mbps |
| Mounting Type | DIN Rail |
| Operating Voltage | 5 VDC |
| Enclosure Rating | IP20 |
| Certifications | CE, UL, CSA |
Industry Applications
In manufacturing plants, it connects remote I/O stations to programmable logic controllers (PLCs), ensuring real-time monitoring and control. For material handling systems, the 170BNP67100 supports high-speed communication at 1 Mbps, reducing latency in automated conveyors and sorters. Its IP20 rating makes it suitable for clean, controlled environments like electrical cabinets.
Installation & Setup Guidance
Mount the 170BNP67100 on a standard DIN rail within an enclosure. Connect the DB9 female port to the Modbus Plus network using a compatible cable. Ensure the operating voltage is 5 VDC from the backplane. The LED status indicators provide immediate visual feedback on network activity and module health. Always power down the system before installation to prevent damage.
Maintenance & Reliability
Periodically inspect the module for dust accumulation on the connector and enclosure. The IP20 rating protects against solid objects larger than 12 mm, but regular cleaning with a dry cloth is recommended. Verify that the operating temperature stays within 0°C to +60°C to maintain reliable performance. No user-serviceable parts are inside; contact a qualified technician for any issues.
The Evolution of Industrial Connectivity
Industrial automation has evolved from proprietary networks to open, robust protocols like Modbus Plus, enabling seamless integration across diverse systems. The Schneider Electric 170BNP67100 communication interface module exemplifies this shift, providing reliable connectivity for the Modicon Momentum series in demanding environments.
Compatibility & Integration
The 170BNP67100 is designed for the Modicon Momentum series and is compatible with TSX Momentum I/O modules. It supports the Modbus Plus protocol, enabling integration with Schneider Electric PLCs and other Modbus Plus devices. The single DB9 port allows straightforward connection to existing networks.
Selection Guide & Purchasing Advice
When selecting a communication interface module, verify that your network protocol matches Modbus Plus and that your backplane provides 5 VDC. The 170BNP67100 is available at AutoDCSTech, a trusted supplier of industrial automation parts. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
Availability & Condition at AutoDCSTech
| Part Number | 170BNP67100 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
